Performance Optimized Down Fire Ported 10" Enclosure | DD Audio SL710

Pulling a 41 Hz driver down to a 29 Hz F3 is the port's job, and on the fixed down fire footprint that sets the power. The 23.4 square inch slot keeps air at the mouth under 17 metres per second, the point where a slot starts to chuff, up to 690 watts, not at DD's 1000 watt rating. The cone is not the limit: at 690 watts it peaks near 9 mm against DD's 19 mm of Xmax. So the port is sized for 690 watts, and that is the power this cabinet is built for. If you plan to run the SL710 at its full 1000 watts, the sealed wedge for the SL710 has no port to limit it. DD publish no vented recommendation of their own, so the 35.0 Hz tuning is our solve against their published T/S set. Tuning is chosen for in-car response rather than for an anechoic curve: a vehicle adds roughly 12 dB per octave below about 45 Hz, so a box tuned very low reinforces a region the cabin is already reinforcing and leaves 40 to 60 Hz thin. In this cabinet that lands at 6.9 dB of in-car spread across 25 to 60 Hz, which is where kick and bass fundamentals live.

No, and on this build in particular do not add any. Every sealed Proline X enclosure ships with polyfill pre-installed; a ported one must not, because damping material changes the effective volume the port is tuned against. The port on this cabinet is cut to 29.64 inches of centreline path for 35.0 Hz. Stuff it and you move the tuning without shortening the port, which gives you a mistuned box rather than a bigger-sounding one. The 2.99 dB passband you are paying for depends on it staying dry.

Yes, at 28 Hz, 24 dB per octave. Below tuning a vented box stops loading the cone and excursion runs away toward DC. With the filter in place this cabinet puts the DD Audio SL710 at 47 percent of its usable travel at full rated power; without it there is no meaningful number to quote, because the excursion curve does not converge. On a sealed build a subsonic filter is an improvement. Here it is required equipment.

690 W RMS. DD Audio rate the SL710 at 1000 W RMS, but on this cabinet the port binds first: the slot is sized for 690 W, and above that the air at the mouth passes the 17 metre per second chuff threshold. The cone is not the limit; it sits at 47 percent of usable travel at DD Audio's rating. If you plan to run the full 1000 W, the sealed wedge for the SL710 has no port to limit it.

Not one we can show you. We do not build a sealed enclosure for the DD Audio SL710 and DD Audio publish no sealed volume for it, so the Performance Graphs tab carries no ported-versus-sealed chart: the only sealed box left to plot would be this cabinet stuffed and sealed, which nobody would build, and a comparison against it would tell you nothing you could buy. What a vented box gives up is the region below tuning, where the cone unloads and the 28 Hz subsonic filter takes over; around 35.0 Hz the vent carries the load and cone travel drops to its minimum, which no sealed alignment can do.

It is a slot port formed by one folded wall: a leg down the long side of the cabinet past the woofer ring, one faceted 90 degree bend, and a leg across the end opening through a chamfered corner. On this cabinet that is 29.64 inches of centreline path and 23.4 square inches of channel, exiting a 30.9 square inch mouth. Air leaves at 17.0 metres per second at tuning against a 17.0 threshold, and the channel runs at 53 percent of its turbulence limit. One wall and one bend rather than a serpentine's three means less wall area inside the box, fewer joints to leak, and one place for flow to separate instead of three.

V-groove and dado joinery in 0.75 inch Langboard Elite MDF with a double-layer 1.5 inch baffle. The driver mounts to a 11.250 inch ring bonded under the baffle in a machined recess, carrying eight #8-32 hurricane nuts so it threads into steel rather than MDF. A windowed brace sits 2.70 inches clear of the cutout edge and 1.76 inches clear of the port terminus; the window is not weight saving, a solid panel there would split the cavity and make the box a bandpass. Walls seat into dados in both the lid and the baffle. Square corners, plush black carpet, side-mounted terminal cup.

No. This is an enclosure only, cut and folded for the DD Audio SL710 specifically. The 9.375 inch cutout, the 5.125 inch mounting depth allowance and the 1.37 cubic foot alignment all come from DD Audio's published parameters for this exact driver, and the port is sized against its Xmax and power rating. It is not a universal box with a 10 inch hole in it. Bring your own driver.
