Prodigy
Prodigy Audio 1000 watt 10 inch Subwoofer | NB5 Series
SKU: NB5-10D4
$ 328.99
$ 393.99
Save
$ 65.00
QUICK SPECS
- Best For: High-Output Daily / Compact SPL Builds
- Power: 1000 Watts RMS
- Topology/Class: High-Excursion Ferrite Driver
- Sonic Character: Authoritative, Heavy, Low-Inductance
Perfectly Paired With
Prodigy Audio 1000 watt 10 inch Subwoofer | NB5 Series
Free Insured Shipping
On orders over $99
Full Warranty
Authorized Dealer
Lifetime Support
Real Installers
INSTALLER'S TAKE
Product Details
Specifications
Box Advisor
FAQs
Recommended Enclosures
Video
High-Excursion Engineering for the Daily Competitor
The Prodigy Audio NB5 Series 10-inch subwoofer isn’t just another driver; it’s a high-displacement machine built for enthusiasts who refuse to compromise on space or output. While many 10-inch woofers fall flat in the sub-30Hz range, the NB5-10 is engineered with a massive 280oz ferrite motor and a 2.75-inch flat-wound aluminum voice coil, allowing it to handle a true 1000 watts RMS while maintaining clinical control over every cycle.
Advanced Induction Control & Thermal Management
Performance at this level requires serious heat dissipation. The NB5-10 utilizes a heavy-duty cast aluminum frame that doubles as a heat exchanger, drawing thermal energy away from the motor. To combat inductive distortion, Prodigy Audio integrated a large inner pole Faraday shorting ring (upper and lower). This stabilizes the magnetic field throughout the cone's travel, resulting in cleaner, more accurate low-frequency reproduction even at extreme volume levels.
Built for Physical Abuse
With a staggering 27mm of one-way linear excursion (70% BL) and up to 50mm of mechanical clearance, this woofer is designed to move air. The competition-grade treated paper cone is supported by a high-roll foam surround and extreme-duty Nomex spiders with double-stitched tinsel leads. Whether you are chasing a high-score in a local lane or simply want a daily driver that can handle the low-end transients of modern bass music, the NB5-10 is the technical solution for high-SPL applications in compact enclosures.
| RMS Power | 1000 Watts |
| Voice Coil | 2.75" Black Aluminum (Flat Wire) |
| Xmax (70% BL) | 27mm (One-Way) |
| Fs (Resonant Frequency) | 37.4 Hz (D2) / 36.9 Hz (D4) |
| Sensitivity | 83.9 dB (D2) / 82.7 dB (D4) |
| Mounting Depth | 7.625" |
| Cutout Diameter | 9.375" |
| Displacement | 0.19 ft³ |
| Motor Weight | 280 oz Ferrite |
Fs
37.4 Hz
÷
Qes
0.557
=
EBP
67
Ideal for Sealed
Ideal for Ported
0
50
100
150
200+
🎯 Recommended Enclosure: Can work in either sealed or ported, though usually leans toward sealed. Consider your goals: sealed for accuracy, ported for efficiency and output.
Pro Tip: EBP is just one factor in enclosure design. Always use complete Thiele-Small parameters and modeling software for optimal results. Our custom enclosures are engineered specifically for each subwoofer's parameters.
Which to Choose?
- Choose Sealed for tighter, punchier, and more accurate sound, or if space is limited
- Choose Ported for max output, deep bass, and high efficiency, especially for genres like hip-hop
Efficiency Bandwidth Product (EBP)
What is EBP?
The Efficiency Bandwidth Product (EBP) is calculated by dividing the subwoofer's resonant frequency (Fs) by its electrical damping (Qes). This single number helps predict which enclosure type will work best with your subwoofer.
How to Use EBP
- EBP < 50: Ideal for Sealed enclosures
- EBP 50-100: Can work in either, though usually leans toward sealed
- EBP > 100: Ideal for Ported enclosures
Enclosure Specifications
| Enclosure | Volume | Tuning |
|---|---|---|
| Sealed | 0.6 - 0.85 ft³ | N/A |
| Ported | 1.25 - 1.5 ft³ | 32 - 35 Hz |
No enclosures have been added to this product yet.
