2015 - 2023 Ford F - 150 & 2017 - 2023 F - 250 Direct Fit Ford Series Loaded Subwoofer Enclosure – Kicker CompRT 10

Proline X

2015-2023 Ford F-150/F-250 Behind-Seat Single 10" Enclosure – Loaded with Kicker CompRT 10

Q: Which trucks does this fit?

The 2015 to 2023 Ford F-150 and the 2017 to 2023 Ford F-250. Ford changed the platform for 2024 and the enclosures are not interchangeable, so a 2024 or later truck needs our 2024 to 2026 build instead. Check your model year before ordering. It is the most common mistake on this line.

Q: Do I lose seat travel or storage?

No. The enclosure is cut for this specific cab rather than adapted to it, so it sits behind the rear bench without fouling the seat or the factory under seat storage. That is the whole reason a vehicle specific build exists. A universal box in the same space either does not fit or costs you something.

Q: Do I need an amplifier, and how much power?

Yes. This is a passive enclosure with no amplification built in. Target 300 to 400 watts RMS at your final impedance. The CompRT 10 is a dual 4 ohm driver, so parallel gives 2 ohms and series gives 8. Most truck builds run 2 ohms into a compact Class D monoblock. If you are keeping the factory head unit you will also need a line output converter or a DSP with speaker level inputs.

Q: Why only 0.50 cubic feet?

It is inside Kicker's published 0.4 to 1.25 cubic foot sealed range for the CompRT 10, and it suits a truck cab specifically. A cab is small, sealed and heavily reinforced, so cabin gain below 80 Hz is stronger there than in almost any other vehicle. A larger box chasing deeper extension usually just produces boom you have to EQ back out. Tighter gives you control and lets the cab do the low end work.

Q: Where do I put the amplifier?

Plan this before the box goes in. The enclosure fills the behind seat space by design, which is where most people were intending to put the amp. A compact Class D monoblock will usually fit under a front seat or against the rear wall beside the enclosure. Route and test your power and signal runs before final placement, because lifting the box back out to fish a wire is not a two minute job.

Q: Will the CompRT handle a truck cab environment?

That is what it was designed for. Both cone and surround are UV resistant, and Kicker's Forced-Air Cooling runs the motor around 20 percent cooler than their previous generation. A cab bakes in summer and freezes in winter, and heat is what kills subwoofers. This driver was built with that in mind rather than adapted to it.

Q: What is the warranty on this system?

The enclosure carries a 2 year limited warranty on craftsmanship and materials, which is the standard across the Vehicle Specific line. The Kicker CompRT 10 carries its own manufacturer warranty separately, handled through Kicker.

Q: Is there a higher output version for the same space?

Yes. We build a PR Edition for the same cab that uses a passive radiator to extend the low end further without needing port length the space does not allow, and a dual 10 version for the same platform if you want more cone area. We also build this cab with the JL Audio 10TW3 and the Alpine RS-W10D4 if you prefer a different driver.

SKU: VS FD1 10-S Kicker CompRT 10

QUICK SPECS

Best For: 2015 to 2023 F-150 and 2017 to 2023 F-250 behind seat
Configuration: Single 10" Sealed — Vehicle Specific, loaded
Volume: 0.50 ft³ Net
Tuning: N/A — Sealed
Sonic Character: Tight, controlled, cab friendly

Proline X Enclosure — Built in Tennessee CNC-cut Langboard Elite 3/4" MDF, V-groove + dado joinery, recessed ABS/Carbon Fiber terminal cup.

Driver + Enclosure — Matched and Pre-Wired Subwoofer pre-installed and wired to the correct impedance. Connect your amplifier and it's ready to run.

Shipping Included No freight charges at checkout on orders to the lower 48. Alaska, Hawaii, and international orders are quoted live rates at checkout.

$ 649.99

Hurry! Only 2 left in stock.

Financing available — choose Shop Pay Installments at checkout.

What's Included

Proline X Vehicle Specific behind seat enclosure, single 10 inch, 0.50 cu ft net
Kicker CompRT 10 subwoofer pre-installed
Pre-wired 12 gauge OFC speaker wire to the terminal cup
Recessed Proline X ABS and carbon fiber terminal cup with stainless hardware and copper ring terminals
Polyfill installed and matched to this volume
Automotive carpet finish

Amplifier, power wire and RCA cables are not included.

2015-2023 Ford F-150/F-250 Behind-Seat Single 10" Enclosure – Loaded with Kicker CompRT 10

$ 649.99

Enclosure Type Sealed

External Dimensions Direct Fit | Passenger Side | Behind Rear Seat

Net Volume 0.50 cu ft

Tuning Frequency N/A - Sealed

Cutout Diameter 9-1/8"

Front Panel Thickness .75"

Max Mounting Depth 3-7/16""

INSTALLER'S TAKE

Check your year before anything else. This fits the 2015 to 2023 F-150 and the 2017 to 2023 F-250. Ford changed the platform for 2024 and the boxes are not interchangeable, so a 2024 truck needs the other build. It is the single most common ordering mistake on this line and it costs a return shipping both ways.

Plan the amplifier location before you set the box. The enclosure fills the behind seat space by design, which is exactly where most people intend to put the amp. A compact Class D monoblock will usually go under a front seat or against the rear wall beside the enclosure, but decide that first rather than discovering it with the box already in.

Run your power and signal before final placement as well. Once the enclosure is seated behind the bench it is not a two minute job to lift it back out to fish a wire. Route, test, then set it and secure it.

Product Details

Proline X Vehicle Specific Series Enclosure for the Kicker CompRT 10

Cut and tuned for the Kicker CompRT 10, built to drop into the 2015-2023 F-150, 2017-2023 F-250

CNC Stack-Fab Langboard Elite MDF 0.50 cu ft Net Fits Kicker CompRT 10 2015-2023 F-150, 2017-2023 F-250

0.50cu ft net

0.910system Qtc

44 HzF3 rolloff

3.4375 inCompRT 10 mounting depth

Built Around the Kicker CompRT 10

Nothing about this box is generic. Every layer is cut to the CompRT 10's published sealed target, with the baffle bored to the CompRT 10's 9.125 in cutout with 8/32 threaded inserts set on the back face, and clearance cut for its 3.4375 in mounting depth.

The CompRT 10 carries a published Fs of 28.7 Hz, Qts of 0.486 and Vas of 35.36 litres, and an EBP of 57, which puts it in transition enclosure territory. We ran the alignment math on that data and built the box to land where it belongs.

Net Volume, Not Gross

We build this cabinet at 0.50 cubic feet net, against a published recommendation of 0.4 to 1.25 cu ft. The volume quoted is true net internal airspace, measured after the walls, bracing and driver displacement are accounted for.

True net, not marketing net. Internal volume is calculated by summing each CNC cut layer's opening, not estimated from external dimensions minus wall thickness.

Proline X Vehicle Specific Series Construction

This enclosure is stack fabricated on our ShopSabre routers from Langboard Elite 3/4 inch MDF, a dense 48.5 lb/ft³ board with a 200 psi internal bond and 410,000 psi MOE. Each layer is cut to the cab profile and the stack does the joining. Dowel reinforcement runs between layers as tension hardware only, which is what lets the shell follow a behind seat contour without a corner joint in it.

Threaded Inserts, Not Wood Screws

8/32 threaded inserts are set on the backside of the baffle so the driver mounts on machine screws. Pull it a dozen times and the threads are still there.

Pre-Wired Terminal Cup

Proline X ABS and carbon fiber composite cup with stainless hardware and copper ring terminals, pre-wired internally with 12 gauge OFC. No CCA anywhere in the build.

Damped and Finished

Polyfill is pre-installed to smooth the in box response, and the shell is wrapped in plush black carpet. Built in Tullahoma, Tennessee.

Enclosure Only or Loaded

Order the enclosure bare and mount your own CompRT 10, or order it loaded and we mount the driver, dress the wiring and ship it ready to bolt in. Loaded builds are available in Dual 2-Ohm (D2) or Dual 4-Ohm (D4), selectable by variant.

Sealed Enclosure Performance: Pre-Calculated

Using the published Thiele Small parameters for the Kicker CompRT 10, here is the predicted Qtc, system resonance (Fc) and F3 rolloff for this enclosure. Calculated with the same formulas as the Audio Intensity Sealed Box Calculator.

Kicker CompRT 10 D2 | Qts 0.486 | Fs 28.7 Hz | Vas 35.36 L

Enclosure Size	Qtc	Fc	F3
0.50 cu ft as built	0.910	53.7 Hz	44.2 Hz

Kicker CompRT 10 Frequency Response | Sealed, 0.50 cu ft

0.50 cu ft (Qtc 0.910) -3dB reference

Note on coil choice: The figures above are the D2 set. The D4 CompRT 10 carries Qts 0.618 and Vas 27.8 litres, and a different Fs of 32.3 Hz, which in this same 0.50 cubic foot volume lands at Qtc 1.064, Fc 55.6 Hz and F3 42.6 Hz. Worth accounting for if you are choosing between the two. Run your own numbers in the Sealed Box Calculator.

Cut for the Driver, Not the Catalog

Select your configuration above. This enclosure ships free to the lower 48 with a 2 year limited warranty, built one at a time in Tullahoma, Tennessee.

Enclosure Specifications

Enclosure	Proline X Vehicle Specific, direct fit behind seat
Fits	2015 to 2023 Ford F-150, 2017 to 2023 Ford F-250
Driver	Kicker CompRT 10, pre-installed
Voice Coil	Dual 4 ohm
Enclosure Type	Sealed
Net Internal Volume	0.50 ft³ Net
Tuning Frequency	N/A — Sealed
Material	Langboard Elite MDF, 3/4" (18mm)
Subwoofer Cutout	9-1/8"
Driver Mounting Depth	3-7/16"
Terminal Cup	Proline X ABS/Carbon Fiber, recessed mount, stainless hardware, copper ring terminals
Wiring	Pre-wired 12g OFC speaker wire
Polyfill	Installed
Finish	Automotive carpet
Built	Tullahoma, Tennessee
Warranty	2-Year Limited on the enclosure

Woofer Details

The Kicker CompRT 10 is built for exactly this kind of install. At a 3-7/16 inch mounting depth it goes behind a rear bench or under a seat where a conventional 10 will not, and unlike a lot of shallow mount drivers it does not achieve that by shrinking the motor and accepting less output. It is rated at 400 watts RMS and 800 watts peak with dual 4 ohm voice coils, and Kicker's Forced-Air Cooling system runs the motor around 20 percent cooler than their previous generation. The cone is injection moulded polypropylene using Kicker's SoloKon design, bonded to an improved Santoprene surround with the signature red double stitching. Both cone and surround are UV resistant, which matters more than it sounds in a truck cab that bakes in summer and freezes in winter. Sensitivity is 84.8 dB, and Kicker specifies a sealed enclosure between 0.4 and 1.25 cubic feet.

Brand + Model	Kicker CompRT 10
Size	10"
RMS Power	400W recommended
Peak Power	800W
Voice Coil Config	Dual 4 ohm
Sensitivity	84.8 dB
Mounting Depth	3-7/16" (8.8 cm)
Mounting Diameter	9-1/8" (23.1 cm)
Cone	Injection moulded polypropylene, SoloKon
Surround	Santoprene, UV resistant
Cooling	Kicker Forced-Air Cooling
Recommended Sealed Volume	0.4 to 1.25 ft³
Driver Warranty	Through Kicker

Why This Combo Works

Kicker CompRT 10 in a Proline X 0.50 Cubic Foot Direct Fit Ford Enclosure

Kicker publishes a sealed range of 0.4 to 1.25 cubic feet for the CompRT 10. This cabinet is 0.50, near the bottom of that range, and that is not a compromise forced by the truck. It is the alignment that suits a cab.

A truck cab is a small, sealed, heavily reinforced space. Cabin gain below 80 Hz is stronger there than in almost any other vehicle, which means a larger box chasing deeper anechoic extension usually just produces boom you then have to EQ back out. A tighter sealed volume raises system Qtc, tightens transient control, and lets the cab do the low end work it was always going to do anyway.

The CompRT is the right driver for the location. At a 3-7/16 inch mounting depth it fits behind the rear bench without fouling the seat or the factory storage, and Kicker's Forced-Air Cooling plus a UV resistant Santoprene surround suit a space that sees real temperature swings. Rated at 400 watts RMS with a sensitivity of 84.8 dB, it does not need a large amplifier to fill a cab.

For amplifier power, target 300 to 400W RMS at your final impedance. The CompRT 10 is a dual 4 ohm driver, so parallel gives you 2 ohms and series gives you 8. Most truck builds run it at 2 ohms into a compact Class D monoblock, which is also the easiest thing to hide under a seat alongside the enclosure.

Materials

Material

Built From a Spec Sheet, Not a Sales Sheet

Every Proline X Performance Series enclosure is CNC-cut from Langboard Elite MDF, 3/4" (18mm) panels produced to published mill specifications. Most enclosure manufacturers source generic MDF without published data. We can tell you the internal bond rating, the modulus of elasticity, the modulus of rupture, and the face and edge screw holding strength for every panel in this enclosure, because we chose the material based on those numbers, not on price or availability.

Langboard Elite is produced in the United States. The specifications below are pulled directly from Langboard's published mill data and are verifiable. This is the same panel stock used in our full Proline X lineup.

Specifications

Langboard Elite MDF: Published Mill Data

Property	Value	Why It Matters
Panel Stock	Langboard Elite MDF	Named, verifiable panel source, not generic "high-density MDF"
Thickness	3/4" (18mm)	Industry standard for subwoofer enclosures; panels below this flex under pressure
Density	48.5 lbs/ft³	Higher density = less porosity, better screw retention, reduced resonance
Internal Bond	200 psi	Measures resistance to delamination under sustained internal pressure. The most enclosure-relevant spec on this sheet
Modulus of Rupture (MOR)	4,200 psi	Bending strength before the panel breaks, relevant for larger unsupported baffle spans
Modulus of Elasticity (MOE)	410,000 psi	Stiffness under load; higher MOE means less panel flex under bass pressure, less resonance
Face Screw Holding	325 lbs	How firmly the panel surface holds a screw; critical for baffle joint integrity over time
Edge Screw Holding	250 lbs	Panel edge retention, relevant for every joint that isn't face-to-face

Internal Bond

200 psi: The Number That Actually Matters for Enclosures

The internal bond rating measures how well the MDF panel resists delamination under sustained pressure applied perpendicular to the face. In a subwoofer enclosure, every bass transient generates a pressure pulse that pushes outward on every panel simultaneously. A panel that begins to delaminate internally loses stiffness gradually. The symptoms are slow: a box that starts to sound softer, less defined, less punchy over months of use. 200 psi internal bond is the spec that determines how long this enclosure holds its acoustic integrity under daily use at real power levels.

Stiffness

410,000 psi MOE: Less Flex, Less Resonance

The modulus of elasticity measures panel stiffness, its resistance to bending under load. A stiffer panel flexes less under the pressure generated by a high-excursion driver at volume. Panel flex is a source of acoustic coloration: the panel itself begins to radiate sound at its own resonant frequency, adding distortion to the output. 410,000 psi stiffness combined with V-groove and dado joinery means the panels stay rigid and the bracing controls resonance at the structure level, not the panel level. The bass you hear comes from the driver, not the box.

Screw Holding

325 lb Face / 250 lb Edge: Joints That Stay Locked

Screw holding strength determines how firmly the panel grips a fastener at the face and at the edge. This matters most at the baffle joint, where the front panel meets the side panels and where the driver is mounted. A panel with low screw holding strength allows fasteners to loosen over time under vibration, leading to air gaps at the joint and loss of acoustic seal. 325 lb face screw holding strength means the baffle hardware stays put. Combined with dado joinery and adhesive, the front panel on a Proline X Performance Series enclosure is not going anywhere.

Sourcing

Named Panel Stock: Not "Premium MDF"

The phrase "premium MDF" or "high-density MDF" appears on marketing copy for enclosures across every price point, from $40 to $400. It is not a specification. It is a description with no defined standard. Langboard Elite is a named, sourced, mill-documented product with published data. We name it in our copy because naming it holds us accountable to the spec. You can look up Langboard Elite independently, verify the numbers on this page, and confirm you are getting what we say you are getting. That is the point.

Why Proline X?

Most enclosures are built to a price point. Proline X is built to a spec. Every box starts with published-data MDF, gets CNC-cut to exact internal volume, and is assembled by hand in our Tennessee facility. The difference shows up in the measurements — and in how the box holds up two years into daily use.

CNC-Cut to Spec

Panels are machine-cut on ShopSabre CNC routers and joined with V-groove and dado joinery. Consistent geometry, no hand-cut variance, no gaps at the joints.
