Arc Audio X2 1100.1 Monoblock Subwoofer Amplifier | 1100W | Class D

The Arc Audio X2 1100.1 produces 350 watts RMS at 4 ohms, 600 watts RMS at 2 ohms, and 1100 watts RMS at 1 ohm, all measured at 14.4 volts. Two X2 1100.1 amplifiers strapped in master/slave configuration produce 2200 watts RMS into a 4-ohm load.

Both are Class D monoblock subwoofer amplifiers with the same control architecture, bandwidth, inputs, strapping system, and installation features. The Arc Audio X2 1100.1 is 4 inches longer at 13.0 inches versus 9.02 inches for the Arc Audio X2 650.1, uses 3 on-board fuses versus 2, and produces more power: 600W versus 350W at 2 ohms, and 1100W versus 650W at 1 ohm. The 1100.1 uses Level 2 cosmetics with an extruded brushed-aluminum chassis and blue illuminated badge, versus the 650.1's Level 1 black steel chassis. Choose the 650.1 for compact installations and lower-power builds; choose the 1100.1 when more headroom is needed.

No. The X2 1100.1 has an output bandwidth of 20 Hz to 230 Hz, optimized for subwoofer use only. Do not connect tweeters, midrange drivers, or full-range coaxial speakers to this amplifier.

Two X2 1100.1 amplifiers can be connected in master/slave configuration using RCA cables between the Slave Out of the master and the Slave In of the slave, with the slave's Input Source switch set to Slave mode. The master amplifier's gain, crossover, subsonic, bass boost, and phase settings govern both units. The slave bypasses all controls except phase. The combined output is 2200 watts RMS into a 4-ohm minimum load.

The adjustable subsonic filter (10-80 Hz) is for excursion protection in ported enclosure applications. At 1100 watts, infrasonic content below the port tuning frequency produces uncontrolled cone travel that can damage the subwoofer within seconds. The subsonic filter should be set at or slightly below the enclosure tuning frequency in all ported builds. In sealed enclosures the filter is less critical but still beneficial for driver protection at high power levels.

Level 1 cosmetics, used on the Arc Audio X2 650.1, feature a black steel chassis shroud with a rotatable diamond-cut aluminum badge. Level 2 cosmetics, used on the Arc Audio X2 1100.1 and X2 2500.1, feature an extruded brushed-aluminum chassis shroud with a blue illuminated acrylic badge that lights during normal operation and flashes diagnostic fault codes when needed. The badge rotates in 90-degree increments on both levels. Level 2 cosmetics are the premium visual presentation of the X2 Series.

Yes. The X2 1100.1 uses balanced differential inputs compatible with common-ground speaker-level outputs and bridged-tied-load factory amplifier outputs. Included speaker-level input RCA pigtails with voltage dividers allow direct connection to factory outputs without an external line output converter in most applications. DC Detect and Signal Detect auto turn-on modes eliminate the need for a dedicated remote wire from the head unit.

The Arc Audio X2 1100.1 carries a 1-year limited warranty against defects in materials and workmanship when purchased from an authorized Arc Audio dealer. Audio Intensity is an authorized dealer. Every unit we sell is brand new current production with full warranty coverage and lifetime tech support.
