Arc Audio Speakers
When it comes to bass, there is no replacement for displacement. Arc Audio 12-inch subwoofers are engineered to maximize cone area and excursion without requiring the massive enclosures typical of other brands. By utilizing advanced motor structures and proprietary stamped steel baskets with compound curves, Arc Audio drivers eliminate chassis resonance, ensuring that the only thing you hear is the music—deep, clear, and impactful.
Choosing the Right 12-Inch Driver
The **X2V2 12"** is the choice for the discerning listener. Optimized for small sealed enclosures (0.85 - 1.0 cu. ft.), it delivers a "Reference" sound profile with exceptional transient response, making fast drum beats sound crisp rather than muddy. For those who want more volume and physical impact, the **ARC Series 12"** features a more robust motor capable of handling 350W RMS and thrives in ported enclosures where it can breathe. Finally, the **A12** is designed for the impossible fit; with a mounting depth of just 3.85 inches, it allows truck owners and sports car drivers to experience deep 12-inch bass without sacrificing legroom or storage.
Technical Features
Across the lineup, Arc Audio employs **High-Temperature Black Anodized Voice Coils**. This critical feature allows the aluminum or copper windings to dissipate heat rapidly, preventing performance loss during extended listening sessions. The **X2V2** and **ARC Series** utilize a "linear" design philosophy, ensuring the cone moves perfectly straight even at high excursion limits. The **A12** shallow subwoofer takes this further with a unique **Progressive Flat Spider** that supports the cone assembly without requiring the depth of a traditional suspension system.
Installation Advice
While Arc Audio subwoofers are forgiving, enclosure size is critical for the 12-inch models. The **X2V2** performs best in a sealed box around 0.9 cu. ft.; going significantly smaller will choke the low-end extension. For the **ARC Series**, a vented enclosure tuned to 32Hz will unlock a massive gain in output (SPL). When installing the **A12**, ensure your enclosure walls are rigid (at least 3/4" MDF) because the air pressure generated by a 12-inch shallow driver is immense and can cause thin boxes to flex and rattle.
