US Acoustics
US Acoustics Wendy | 2 Channel Class AB Amplifier | 2 x 75w
SKU: wendy
$ 159.99
QUICK SPECS
- Power: 75W x 2 @ 4 Ohms | 125W x 2 @ 2 Ohms | 250W x 1 Bridged @ 4 Ohms
- Topology: Full Complementary Class AB | THD Below 0.01%
- Best For: Tight Install Spaces | Compact Component Setups | Add-On Channels
- Size: 7.5 x 8.9 x 2.2 in | Smallest Chassis in the US Acoustics Line
US Acoustics Wendy | 2 Channel Class AB Amplifier | 2 x 75w
Regular price
$ 159.99
Sale price
$ 159.99
Regular price
Unit price
Free Insured Shipping
On orders over $99
Full Warranty
Authorized Dealer
Lifetime Support
Real Installers
INSTALLER'S TAKE
Product Details
Specifications
FAQs
Related Products
Related Video
US Acoustics Analog 2-Channel Series
US Acoustics Wendy 2-Channel Class AB Amplifier
Spunky Power. Real Full Complementary Class AB in the smallest chassis US Acoustics makes, 7.5 inches of amplifier that fits where nothing else will.
75W x 2 @ 4 Ohms
125W x 2 @ 2 Ohms
250W x 1 Bridged @ 4 Ohms
2-Year Warranty
The Smallest Amplifier in the Line, Built Like the Biggest
The US Acoustics Wendy delivers 75 watts RMS per channel into 4 ohms and 125 watts RMS per channel into 2 ohms, with 250 watts RMS available bridged into a 4-ohm mono load, all rated honestly at 14.4 volts. It uses the same Full Complementary Class AB topology as the rest of the US Acoustics analog family, with total harmonic distortion below 0.01 percent and frequency response from 10 Hz to 30 kHz within half a decibel.
What makes the Wendy different is the package: 7.5 inches long, 8.9 wide, 2.2 tall. That is the smallest footprint in the entire US Acoustics catalog, small enough for under-seat mounting, console cubbies, and behind-panel spaces where a full-size amplifier was never an option. There is no Class AB penalty hiding in the size, either, the same Butterworth filters, Docking Pads, and protection suite carry over from the big amps.
7.5 inChassis Length
<0.01%THD
>95 dBS/N Ratio
>100Damping Factor
Butterworth Crossovers Onboard
The Wendy carries the same serious filter set as its bigger siblings. The 12 dB per octave Butterworth high-pass sweeps from 80 Hz to 1.2 kHz for component and coaxial duty, and the 24 dB per octave low-pass sweeps from 10 to 250 Hz for bridged subwoofer use. There is no bass boost, remote, subsonic filter, or phase control on this model, the Wendy keeps it simple.
Three Ways to Run the Wendy
Compact Component Front Stage
75 clean Class AB watts per channel is a meaningful upgrade over any head unit and a proper match for quality components in a daily driver, especially when install space is the limiting factor.
Bridged Compact Subwoofer
Bridged to 250 watts RMS into 4 ohms with the low-pass engaged, the Wendy makes a tidy power source for a small sealed subwoofer build where the amplifier needs to disappear into the install.
The Add-On Channel Pair
In a larger system, the Wendy is the easy answer when you need two more quality channels, rear fill, a center build, or dedicated duty, without re-engineering the amp rack to fit another full-size chassis.
Install notes: onboard fusing is a single 30A fuse. Class AB runs warmer than Class D, so even at this size give the Wendy airflow rather than sealing it into a tight cavity. Angled terminals keep the wiring clean in confined mounting spots.
Built to the US Acoustics Standard
Docking Pads reduce vibration transfer to extend amplifier life, protection circuitry covers DC, short circuit, thermal, and overload conditions, and diagnostic LEDs make troubleshooting fast. Every Wendy sold by Audio Intensity is brand new from US Acoustics with a 2-year warranty through authorized dealers.
Authorized US Acoustics Dealer
Audio Intensity ships the US Acoustics Wendy fast from Tullahoma, Tennessee, with real installer support before and after the sale. Tight on space and not sure what fits? Send us your measurements and we will tell you straight whether the Wendy is the right amp for the spot.
| US Acoustics Wendy Specifications | |
|---|---|
| Output Power @ 14.4V | |
| RMS per Channel @ 4 Ohms | 75W x 2 |
| RMS per Channel @ 2 Ohms | 125W x 2 |
| RMS Bridged Mono @ 4 Ohms | 250W x 1 |
| 1 Ohm Stable | No |
| Performance | |
| Amplifier Topology | Full Complementary Class AB |
| Total Harmonic Distortion (THD) | Less than 0.01% |
| Signal-to-Noise Ratio | Greater than 95 dB |
| Channel Separation | Greater than 85 dB |
| Frequency Response | 10 Hz to 30 kHz, +/- 0.5 dB |
| Damping Factor @ 100 Hz, 4 Ohms | Greater than 100 |
| Input Sensitivity | 200 mV to 6.0V |
| Crossovers | |
| Crossover Type | Butterworth |
| High-Pass Filter (12 dB/octave) | 80 Hz to 1.2 kHz |
| Low-Pass Filter (24 dB/octave) | 10 Hz to 250 Hz |
| Subsonic Filter | No |
| Bass Boost | No |
| Wired Remote Bass Control | No |
| Phase Shift | No |
| Physical and Protection | |
| Fusing | 1 x 30A |
| Terminals | Angled for clean installations |
| Vibration Control | Docking Pads |
| Protection Circuitry | DC, Short Circuit, Thermal, Overload |
| Diagnostic LEDs | Yes |
| Dimensions (L x W x H) | 7.5 x 8.9 x 2.2 in |
| Warranty | 2 Years (Authorized Dealers) |
