Goldhorn DSPA 1216 Plus (Previous Demo)
Goldhorn DSPA 1216 Plus (Previous Demo)
Goldhorn DSPA-1216 Plus
24-Channel DSP & 1100W Amplifier
Ultimate multi-channel audio processor for high-end car audio enthusiasts featuring advanced 24-channel DSP system and powerful 12-channel amplification.
Professional Features
Advanced 24-Channel DSP System
ADAU1463 DSP chip with precision control
Powerful Multi-Channel Amplification
8×80W + 4×150W Class AB amplification
Precise Audio Management
31-band EQ with advanced crossover options
SKYATOM Ready
Future-ready connectivity and integration
Ultimate Car Audio Upgrade
Enhance your driving experience with the Goldhorn DSPA-1216 Plus, a cutting-edge amplifier and DSP combo that delivers powerful, customizable sound. Designed for car audio enthusiasts, this system ensures clear, detailed, and immersive audio for any vehicle.
Next-Level Sound Customization
24-channel DSP for precise control over your entire audio setup
High-Efficiency Amplification
1100W total power output with distortion-free performance
Seamless Integration
Compatible with both OEM and aftermarket systems
Technical Specifications
| Specification | Details |
|---|---|
| DSP Chip | ADAU1463 |
| DAC Chip | 2 x AK4458VN |
| ADC Chip | 4 x PCM1840 |
| Opamp | MC33078 |
| Amplifier Outputs | 8 x 80W + 4 x 150W (1100W Total) |
| DSP Channels | 24 Channel Processing |
| RCA Outputs | 16 x 6V |
| Input Options | 8 x Hi-Level / 2 x RCA / Optical / Coaxial / Bluetooth |
| Output EQ | 31 Bands per Channel @ ±15dB in 0.1dB Steps |
| Crossover Options | Butterworth & Bessel: 6-48dB / Linkwitz: 12-36dB |
| Time Delay | 0 ~ 20ms / 0.02ms Steps |
| Frequency Response | 20Hz ~ 40kHz |
| Operating Voltage | 10V ~ 16V |
| Dimensions (mm) | 331 x 217 x 43 |
| Fuse Rating | 100A (Not Supplied) |
| Finish | Black Anodized Aluminum |
| THD+Noise (Amplifier) | < 0.03% |
| S/N Ratio (Amplifier) | > 100dB |
| Built-in Bluetooth | Yes |
| Software Compatibility | 64-bit Windows 8/8.1/10/11 |
| SKYATOM Ready | Yes |
Advanced Audio Processing
24-Channel DSP System
Precise Audio Management
Advanced 24-channel DSP allowing for highly detailed control of each audio channel with precision frequency response and time alignment adjustments.
Customizable Sound Profiles
Store and recall different settings based on preferences with easy-to-use software interface for creating multiple configurations.
Multi-Channel Amplification
High Power Output
1100W amplifier with eight channels of 80W RMS and four channels of 150W RMS, ensuring ample power for comprehensive speaker systems.
Multiple Output Options
16 RCA and multiple high-level outputs allow users to drive various speaker configurations with individual channel optimization.
Connectivity & Integration
Versatile Input Options
High-level and low-level inputs with optical and coaxial digital inputs for integration with various audio systems.
Signal Processing Capabilities
Advanced signal summing and processing ensure optimal performance across all frequency ranges with factory and aftermarket systems.
Professional-Grade Components
Premium DAC Technology
Dual AK4458VN DACs provide exceptional digital-to-analog conversion for pristine audio quality and minimal noise floor.
Protection Systems
EPS Error Protection System and start-stop readiness ensure reliable operation and component longevity in demanding environments.
Future-Ready Technology
SKYATOM ready architecture ensures compatibility with future Goldhorn ecosystem expansions and connectivity options.
