AudioControl D-5.1300 1300w D-Series 5-Channel Car Amplifier with DSP | Previous Display
Regular price
$ 355.89
Sale price
$ 355.89
Regular price
$ 889.99
Unit price
Product Details
AudioControl
D-5.1300
Previous Display | High-Power 5-Channel DSP Matrix Amplifier with AccuBASS®
1300W RMS Total Power | Built-In Digital Signal Processor
***USB Cable ( DSP to PC ) not included.
$889.99
Premium DSP Amplifier Solution
Expert Rating
Why This Amplifier Stands Out
The AudioControl D-5.1300 represents the pinnacle of integrated amplifier technology, combining 1300 watts of total RMS power with a professional-grade DSP matrix processor in a single chassis. This amplifier eliminates the need for separate DSP units while delivering AudioControl's legendary sonic purity and unprecedented tuning flexibility. The DM Smart DSP app, 30-band EQ, input/output RTA, and AccuBASS® technology make this the ultimate single-amp solution for audiophiles and professionals demanding complete control over their audio system.
Power Output Specifications
| Configuration | Power Output | Application |
|---|---|---|
| Channels 1-4 @ 4Ω | 4 × 100W RMS | Front/Rear Speakers |
| Channel 5 @ 4Ω | 1 × 300W RMS | Subwoofer |
| Channels 1-4 @ 2Ω | 4 × 200W RMS | High-Performance Speakers |
| Channel 5 @ 2Ω | 1 × 500W RMS | High-Power Subwoofer |
| Bridged Ch 1+2 @ 4Ω | 1 × 400W RMS | Center Channel / Midbass |
| Bridged Ch 3+4 @ 4Ω | 1 × 400W RMS | Center Channel / Midbass |
| Total System Power | 1300W RMS | Complete System Solution |
💡 Configuration Flexibility
The D-5.1300 can be configured as a true 5-channel amp (4 speakers + 1 sub) or as a 3-channel amp (2 bridged pairs + 1 sub) depending on your system requirements. The DSP matrix allows any input to route to any output with independent crossovers and EQ—unprecedented flexibility for custom installations.
Technical Specifications
Amplifier Class
Class D (High-Efficiency)
Total RMS Power
1300 Watts
Channels
5-Channel (Configurable as 3-Channel)
Built-In DSP
Full Matrix Processor with DM Smart App
Signal-to-Noise Ratio
102 dBA (ref 200W @ 2Ω)
THD+N
< 0.1%
Frequency Response
20 Hz – 22 kHz
Speaker-Level Inputs
8 Channels (Summable, 40V Max)
Line-Level Inputs
6 Channels (Balanced RCA, 6V Max)
Line-Level Outputs
2 Channels (Balanced RCA, 6V Max)
Crossover Slopes
12 dB/oct or 24 dB/oct (Linkwitz-Riley)
Equalizer
30-Band Graphic EQ
Real-Time Analyzer
Input & Output RTA
Signal Delay
Independent Per Channel
Auto Turn-On
GTO™ Signal Sense Technology
Level Matching
MILC™ Technology (Patent Pending)
Fuse Rating
4 × 30 Amps (120A Total)
Power Wire Gauge
0 AWG to 4 AWG
Dimensions (W×D×H)
12.00" × 7.95" × 2.10"
Weight
7.2 lbs
Remote Control
ACR-3 (Optional)
Bluetooth Adapter
ACBT24 (Optional)
Memory Presets
4 User Presets
USB Connection
Micro-USB for Computer Tuning
Advanced DSP Features
DM Smart DSP App: Complete control via computer software with intuitive interface
Dual RTA: Input and Output Real-Time Analyzer for precise tuning
30-Band EQ: Graphic equalizer with 1/3-octave resolution per channel
Matrix Routing: Any input can route to any output with summing capability
Signal Delay: Independent time alignment for each channel
Linkwitz-Riley Crossovers: Independent crossovers with 12/24 dB slopes
AccuBASS®: Patented bass restoration technology (Patent #9,225,305)
4 Memory Presets: Save and recall tuning configurations instantly
8 Speaker-Level Inputs: Summable inputs for OEM integration (40V max)
6 Line-Level Inputs: Balanced RCA inputs (6V max)
GTO™ Signal Sense: Automatic turn-on when signal detected
MILC™ Technology: Maximum Input Level Control prevents clipping
Key Features & Benefits
Single-Amp Solution: Complete system amplification in one chassis
OEM Integration Ready: 8 speaker-level inputs handle factory systems
Professional DSP: Studio-grade signal processing built-in
High Efficiency: Class D topology minimizes heat and power draw
Compact Design: 12" × 7.95" × 2.1" fits most installations
Bridgeable Channels: 1+2 or 3+4 for high-power applications
Protection Circuits: Thermal, short-circuit, and overcurrent protection
Visual Feedback: LED indicators for power, protection, and signal levels
ACR-3 Compatible: Optional remote for level and preset control
Bluetooth Ready: Optional ACBT24 adapter for wireless streaming
Low Noise: 102 dBA signal-to-noise ratio
Low Distortion: <0.1% THD+N for pristine audio quality
Installation & Wiring Guide
⚠️ CRITICAL: Power Wiring Requirements
This amplifier requires 0 AWG to 4 AWG power and ground wiring. With 1300 watts total RMS power and 4×30A fuses (120A total), inadequate wiring will cause voltage drop, thermal issues, and potential fire hazard. Use high-quality OFC copper wire with proper fuse protection at the battery.
Recommended Power Wiring
Power Wire Gauge
0 AWG (Recommended) or 4 AWG (Minimum)
Ground Wire Gauge
Same as Power Wire (0-4 AWG)
Fuse Rating
4 × 30A (Installed) + Main Fuse at Battery
Remote Turn-On Wire
18-20 AWG (or use GTO™ signal sense)
Input Connection Options
Speaker-Level Inputs (8 Channels): Connect factory amplifier outputs up to 40V
Line-Level Inputs (6 RCA): Connect aftermarket head unit preouts
GTO™ Signal Sense: Auto turn-on from inputs 1-2 (no remote wire needed)
Bluetooth Option: ACBT24 adapter plugs into Option Port
Output Configuration
5-Channel Mode: Ch 1-4 for speakers + Ch 5 for subwoofer
3-Channel Mode: Bridge Ch 1+2 and 3+4 for front stage + Ch 5 for sub
Line-Level Outputs: 2 RCA outputs for daisy-chaining additional amps
Minimum Impedance: 2Ω per channel, 4Ω bridged
Mounting & Ventilation
Mounting Location: Install in trunk, cargo area, or under front seats (if space permits). Ensure adequate ventilation around the amplifier—Class D amps run cool, but proper airflow prevents thermal protection activation. Mount using four corner holes with M4 hardware. Keep away from moisture, direct sunlight, and excessive heat sources.
Tuning Setup
Step 1: Connect USB Micro cable to computer
Step 2: Install DM Smart DSP app from audiocontrol.com
Step 3: Use MILC™ LED to set input levels (prevents clipping)
Step 4: Configure matrix routing, crossovers, and EQ
Step 5: Use Input/Output RTA for final frequency tuning
Step 6: Save up to 4 memory presets for different sources
System Design Recommendations
Configuration #1: Full 5-Channel System
Best For: Complete 4-speaker + subwoofer systems
- Channels 1-2 @ 2Ω: Front component tweeters/midbass (200W × 2)
- Channels 3-4 @ 2Ω: Rear coaxials or fill speakers (200W × 2)
- Channel 5 @ 2Ω: 10" or 12" subwoofer (500W)
- Total Output: 1300W RMS across 5 channels
Configuration #2: High-Power 3-Channel
Best For: Front-stage focus with powerful subwoofer
- Bridge Ch 1+2 @ 4Ω: Left midbass driver (400W)
- Bridge Ch 3+4 @ 4Ω: Right midbass driver (400W)
- Channel 5 @ 2Ω: Subwoofer (500W)
- Note: Use separate tweeter amp or passive crossovers
Configuration #3: OEM Integration
Best For: Factory system upgrades without replacing head unit
- Input: Connect 8 speaker-level inputs from factory amp
- DSP Processing: Use matrix summing and EQ to correct factory tuning
- Output: Channels 1-4 to upgraded speakers + Ch 5 to new subwoofer
- GTO™: Auto turn-on eliminates need for remote wire
💡 Pro Tuning Tip
The D-5.1300's dual RTA (input and output) is your secret weapon. Use Input RTA to verify source signals are balanced, then use Output RTA to fine-tune frequency response at each speaker location. The 30-band EQ with 1/3-octave resolution allows surgical correction of cabin acoustics. Save multiple presets for different listening preferences (rock, classical, bass-heavy, etc.).
Speaker Pairing Recommendations
Component Speakers (Channels 1-4)
Power Handling: 75-200W RMS per speaker
Impedance: 2Ω or 4Ω (2Ω for maximum power)
Sensitivity: 88+ dB recommended for efficiency
Ideal Matches: Focal, Hertz, Morel, DLS, Rainbow components
Subwoofer (Channel 5)
Power Handling: 300-500W RMS
Impedance: 2Ω DVC (wire to 2Ω) or 4Ω single coil
Enclosure: Sealed (0.75-1.5 cu ft³) or ported
Size Range: 10"-12" for music, 12"-15" for SPL
Bridged Applications (Channels 1+2 or 3+4)
Power Handling: 300-400W RMS per speaker
Impedance: 4Ω minimum in bridged mode
Applications: High-power midbass, center channel, or additional subwoofer
Note: Use 1+ and 2- terminals for bridging channels 1+2
Pros & Cons Analysis
✅ Strengths
- All-in-One Solution: 1300W amp + professional DSP in single chassis
- Exceptional Flexibility: Matrix routing allows any input to any output
- Professional Tuning: 30-band EQ, dual RTA, and signal delay
- OEM Integration: 8 speaker-level inputs handle factory systems
- AccuBASS® Technology: Patented bass restoration
- High Efficiency: Class D runs cool with low power draw
- Low Noise/Distortion: 102 dBA SNR, <0.1% THD+N
- Compact Design: 12" × 7.95" × 2.1" fits most locations
- DM Smart App: Intuitive computer-based tuning interface
- 4 Memory Presets: Save different tuning configurations
- MILC™ Technology: Prevents input clipping automatically
- GTO™ Signal Sense: No remote wire needed
⚠️ Considerations
- Premium Investment: $889.99 price point (but includes DSP worth $300-500)
- Learning Curve: DSP tuning requires time and knowledge
- Computer Required: Initial setup needs laptop/PC (no mobile app tuning)
- Power Wiring: Requires 0-4 AWG wire and proper installation
- Channel 5 Bridging: Not specified (physics limitations)
- Remote Sold Separately: ACR-3 remote is optional ($50-70)
- Bluetooth Optional: ACBT24 adapter not included ($60-80)
- Setup Complexity: Full feature utilization requires expertise
Ideal Applications
OEM Upgrades: Replace factory systems without head unit changes
Audiophile Builds: Sound quality-focused installations
Professional Installs: Shops offering custom tuning services
Full-Range Systems: Complete 4-speaker + subwoofer setups
Front-Stage Focused: Bridged channels for high-power midbass
Complex Systems: Multi-way active crossovers with time alignment
Space-Limited Installs: Single-amp solution saves trunk space
Multiple Listening Modes: 4 presets for different genres/preferences
What's NOT Ideal For
Budget Builds: $889.99 exceeds entry-level budgets (consider LC-5.1300 instead)
Plug-and-Play Users: DSP tuning requires knowledge and time investment
Extreme SPL: 1300W total insufficient for competition-level SPL systems
Multiple Subwoofers: Channel 5 limited to 500W (use dedicated sub amp for 2+ subs)
DIY Beginners: Complex feature set may overwhelm first-time installers
Mobile Tuning: Requires laptop (no iOS/Android app for DSP adjustments)
Warranty & Support
Manufacturer Warranty
1 Year (AudioControl)
Manufacturer
AudioControl (USA)
Country of Origin
Designed in USA
Technical Support
audiocontrol.com/support
Software Downloads
DM Smart App (Free)
Installer Locator
audiocontrol.com/find-installers
Final Recommendation
🏆 Outstanding Professional-Grade DSP Amplifier
The AudioControl D-5.1300 is the ultimate single-amplifier solution for audiophiles and professional installers who demand complete control over their audio system. With 1300 watts of total RMS power, a full-featured DSP matrix processor, and AudioControl's legendary build quality, this amplifier eliminates the need for separate DSP units while delivering exceptional sonic purity.
The DM Smart DSP app, 30-band EQ, dual RTA, AccuBASS® technology, and matrix routing capabilities provide unprecedented tuning flexibility. The ability to configure as a 5-channel or 3-channel amp, combined with 8 speaker-level inputs for OEM integration, makes this amplifier incredibly versatile.
At $889.99, the D-5.1300 represents excellent value when you consider it includes both a high-power 5-channel amplifier and a professional-grade DSP processor (worth $300-500 standalone). The low noise floor (102 dBA SNR), minimal distortion (<0.1% THD+N), and compact footprint (12" × 7.95" × 2.1") make it ideal for high-performance installations where space and sound quality are priorities.
Bottom Line: If you're serious about sound quality and want a single-amp solution with professional-grade DSP capabilities, the AudioControl D-5.1300 is an outstanding investment. Be prepared to spend time learning the DSP features—the effort will be rewarded with audio performance that rivals systems costing thousands more. Highly recommended for OEM upgrades, audiophile builds, and professional installations. Rating: 4.8/5.0 — OUTSTANDING.
