Goldhorn P2 DSPA Pro | 16 Channel DSP/DSD Player with 8x80w Amplifier (Previous Demo)

Goldhorn P2 DSPA Pro | 16 Channel DSP/DSD Player with 8x80w Amplifier (Previous Demo)

Regular price $ 1,199.99
Sale price $ 1,199.99 Regular price $ 1,599.99
Unit price
Overview
Overview

🔥 PREVIOUS DEMO MODEL 💎 PREMIUM DEMO UNIT ⚡ EXHIBITION READY

Goldhorn P2 DSPA Pro

The Ultimate Symphony of Digital Signal Processing & High-Resolution Audio Excellence

8×80W

Class D Amplification

31-Band

Precision EQ DSP

DSD256

Hi-Res Audio Support

16-Ch

Total Output Matrix

🎼 Professional Excellence Redefined

Masterfully engineered for the most discerning audiophiles who demand perfection

The Goldhorn P2 DSPA Pro represents the pinnacle of automotive audio engineering, seamlessly integrating a comprehensive suite of professional-grade components into a single, elegant masterpiece. This versatile powerhouse combines cutting-edge digital signal processing, high-powered amplification, and audiophile-quality hi-resolution playback capabilities.


Integrated 31-Band EQ DSP Module

Professional-grade ADAU1452 DSP processor delivers surgical precision in frequency response tuning with 31 parametric bands per channel.

  • ±15dB adjustment range in 0.1dB steps
  • Peak, High Shelf, Low Shelf filtering
  • 1st & 2nd order All-Pass filters
  • Q factor control from 0.5 to 15

High-Powered Digital Amplifier Matrix

Eight channels of pristine Class D amplification delivering 80 watts per channel for extraordinary dynamic range and crystal-clear reproduction.


  • THD+N < 0.02% at full power
  • Signal-to-noise ratio >100dB
  • Efficient Class D topology
  • Individual channel gain control

Cutting-Edge Bluetooth 5.0 Player

Advanced wireless connectivity with aptX-LL and aptX-HD codec support for lossless audio transmission and ultra-low latency performance.

  • aptX-HD for 24-bit wireless audio
  • aptX-LL for <40ms latency
  • Multiple device pairing
  • Auto-reconnection technology

Hi-Resolution Audio Excellence

Premium TI PCM1690 DAC chipset with 24-bit/192kHz PCM processing and native DSD support up to DSD256 for audiophile-grade reproduction.

DSD256 FLAC WAV APE AIFF
  • Native DSD processing up to 256x
  • PCM support up to 192kHz/24-bit
  • Lossless format compatibility
  • Dual PCM1840 ADC conversion

⚙️ Technical Specifications Matrix

Precision-engineered components delivering uncompromising performance

🔧 Core Processing

DSP Processor ADAU1452
DAC Chipset TI PCM1690
ADC Conversion 2× PCM1840
Operational Amplifiers NJM4580 & MC33078

⚡ Power & Performance

Amplifier Output 8× 80W @ 4Ω
Operating Voltage 11V - 16V DC
Fuse Rating 40A
Frequency Response 20Hz - 40kHz

🎚️ DSP Processing

Output EQ Bands 31 per channel
Input EQ Bands 5 bands
Crossover Slopes 6-48dB/octave
Time Alignment 0-20ms (0.02ms steps)

🔊 Audio Quality

RCA THD+N <0.003%
Amplifier THD+N <0.02%
S/N Ratio (Analog) 108dB
S/N Ratio (Digital) 111dB

📐 Physical Dimensions

Dimensions (L×W×H) 217×170×43mm
Finish Red Anodized Aluminum
Mounting Compact Installation
Operating Temp -10°C to +60°C

💾 Storage & Presets

Memory Presets 8 User Presets
Password Protection Yes
Auto Mode Switching Yes
Navigation Priority Input Priority Mode

🚀 Advanced Features & Technology

Revolutionary innovations that redefine automotive audio excellence


Intelligent Crossover System

Professional-grade crossover network with multiple filter topologies and variable phase rotation capabilities.

  • Butterworth & Bessel filters: 6-48dB/octave
  • Linkwitz-Riley: 12, 24, 36dB slopes
  • Variable phase shift 0-359°
  • Frequency range: 20Hz-20kHz
  • 1dB step precision adjustment

Master Gain & Channel Control

Comprehensive level management system with individual channel control and linking functions for professional system tuning.

  • Master gain: 0-60dB range
  • Channel gains: -20dB to +5dB
  • Polarity reversal (0°/180°)
  • Volume linking (absolute/relative)
  • EQ linking capabilities

Premium Component Selection

Audiophile-grade components selected for ultimate reliability and sonic performance in demanding automotive environments.

  • High-temp 105°C electrolytic capacitors
  • WIMA film capacitors for pristine signal path
  • Premium operational amplifiers
  • Start-stop vehicle compatibility
  • EPS error protection system

Advanced Input Mixer & Navigation

Sophisticated input management system with automatic mode switching and navigation priority for seamless integration.

  • Input mixer with priority control
  • Automatic mode switching
  • Navigation mode with input priority
  • Analog noise gate technology
  • Variable power-off delay

🔌 Connectivity & Control Matrix

Comprehensive I/O configuration for maximum system flexibility

🎧 Audio Inputs

  • 8× High-Level Inputs (24V sensitivity)
  • 2× RCA Line Inputs (4V sensitivity)
  • 6Ω high-level input impedance
  • No impedance adapter required
  • Auto turn-on via DC offset/signal sensing

📡 Digital & Wireless

  • Bluetooth 5.0 with aptX-LL/HD
  • Built-in Wi-Fi connectivity
  • 3× USB 2.0 Host ports
  • USB-B PC connection
  • Mobile app control support

🔊 Output Configuration

  • 8× RCA Pre-outputs (6V maximum)
  • 8× Amplified Speaker Outputs
  • Remote turn-on output
  • 16-channel total output matrix
  • Individual output level control

🎮 Control Options

  • Bluetooth wireless player remote
  • Optional wired panel controller
  • IPS display screen integration
  • Wi-Fi mobile app control
  • PC software interface (Windows 7+)

⚡ SKYATOM Advanced Processing Technology

Revolutionary signal processing architecture delivering unprecedented audio clarity and precision

🧠 Neural Processing Engine

Advanced algorithms analyze and optimize audio signals in real-time, automatically adjusting for optimal sound reproduction based on acoustic environment and source material characteristics.

🎯 Precision Time Alignment

Ultra-precise timing correction with 0.02ms resolution ensures perfect phase coherence across all channels, creating an immersive three-dimensional soundstage.

🔧 Dynamic Range Optimization

Intelligent dynamic range compression and expansion maintains musical dynamics while preventing distortion during high-output passages and preserving detail in quiet sections.

📊 Spectral Analysis Suite

Real-time frequency analysis with visual feedback enables precise system tuning and optimization, providing professional-level measurement capabilities.

🎼 Symphony of Innovation

The Goldhorn P2 DSPA Pro transcends conventional automotive audio boundaries, representing a paradigm shift in mobile sound reproduction technology. This meticulously crafted masterpiece seamlessly integrates cutting-edge digital signal processing, audiophile-grade high-resolution playback, and professional amplification into a singular, elegant solution.


From its premium TI PCM1690 DAC chipset delivering pristine 24-bit/192kHz reproduction to its sophisticated ADAU1452 DSP processor enabling surgical precision tuning, every component has been selected for uncompromising performance. The revolutionary plug-and-play installation philosophy ensures that achieving audio nirvana requires no complex modifications or extensive rewiring.


This previous demo model represents an exceptional opportunity to experience reference-grade automotive audio at an unprecedented value. Transform your daily commute into a concert hall experience with the P2 DSPA Pro – where innovation meets perfection.
