Helix builds their Esprit subwoofers to fit in places that normal subs won't. Coming in at just 3-1/2" deep, the Esprit E12W 12" shallow-mount sub lets you get creative with placement while giving you impressive bass. German engineering shines through on this sub, as Helix uses technology from their high-end Precision Series to create a super-slim driver that delivers superior performance and handles plenty of power. You'll enjoy highly accurate bass reproduction in applications where space is an issue.

• 12" shallow-mount subwoofer with dual 2-ohm voice coils
• fiberglass coated honeycomb membrane woofer with rubber surround
• die-cast aluminum frame
• power range: 100-400 watts RMS (600 watts peak power)
• frequency response: not available
• sensitivity: 88 dB
• top-mount depth: 3-1/2"
• sealed box volume: 0.90 cubic feet
• ported box volume: 1.75 cubic feet

The MATCH for you

If you know Audiotec Fischer's commitment to quality, then you probably have an idea of how exquisite their MATCH Series speakers sound. The MS6X 2-way car speaker uses a 6-3/4" high-damping treated paper woofer cone for nuanced sound and precise play. The integrated tweeter handles the high-frequency acrobatics with ease, thanks to a dynamic neodymium magnet. And the tweeter's polymer dome structure delivers that crisp sound you listen for in your highs.

German-crafted sound in almost any ride

Up to now, MATCH has focused its attention on direct-fit solutions for German-made vehicles. With the MS6X, they've applied their talents for masterful sound engineering to a speaker designed to fit the factory opening of a wide variety of cars. This speaker's shallow build makes it an easier fit than many upgrades in its class. Match the MS6X with a MATCH DSP for a serious improvement to the audio in your car.

• 2-way car speakers (pair)
• 6-3/4" treated paper woofer cone
• 3/4" polymer dome tweeter
• power range: 2-45 watts RMS (135 watts peak power)
• frequency range: 60-22,000 Hz
• sensitivity: 91 dB
• top-mount depth: 2-5/16"
• impedance: 4 ohms
• grilles included

If you know Audiotec Fischer's commitment to quality, then you probably have an idea of how exquisite their MATCH Series of speakers sound. The MS62C component system uses finely tuned, compact external crossover networks for a seamless frequency response. The crossovers assign the lows and midrange to the 6-3/4" woofers, which are made of a high-damping treated paper for nuanced sound and precise play. The 1" tweeters handle the high-frequency acrobatics with ease, thanks to dynamic neodymium magnets. And the tweeter's silk dome structure delivers that smooth sound you listen for in your highs.

Product Highlights:

• The component system includes two woofers, two 1" tweeters, and two crossovers
• 6-3/4" coated paper woofer with rubber surround
• 1" silk dome tweeter
• tweeter flush-mounting and top-mounting gear included
• works with factory radio, aftermarket receiver, or outboard amp
• 2-50 watts RMS power range (150 watts peak)
• frequency response: 55-22,000 Hz
• impedance: 4 ohms
• sensitivity: 91 dB
• woofer mounting depth: 2-5/16"

The MATCH for you

If you know Audiotec Fischer's commitment to quality, then you probably have an idea of how exquisite their MATCH Series speakers sound. The MS5X 2-way car speaker uses a 5-1/4" high-damping treated paper woofer cone for nuanced sound and precise play. The integrated tweeter handles the high-frequency acrobatics with ease, thanks to a dynamic neodymium magnet. And the tweeter's polymer dome structure delivers that crisp sound you listen to in your highs.

German-crafted sound in almost any ride

Up to now, MATCH has focused its attention on direct-fit solutions for German-made vehicles. With the MS5X, they've applied their talents for masterful sound engineering to a speaker designed to fit the factory opening of a wide variety of cars. This speaker's shallow build makes it an easier fit than many upgrades in its class. Match the MS5X with a MATCH DSP for a serious improvement to the audio in your car.

• 2-way car speakers (pair)
• 5-1/4" treated paper woofer cone
• 3/4" polymer dome tweeter
• power range: 2-40 watts RMS (120 watts peak power)
• frequency range: 70-22,000 Hz
• sensitivity: 90 dB
• top-mount depth: 1-7/8"
• impedance: 4 ohms
• grilles included

If you know Audiotec Fischer's commitment to quality, then you probably have an idea of how exquisite their MATCH Series of speakers sound. The MS52C component system uses finely tuned, compact external crossover networks for a seamless frequency response. The crossovers assign the lows and midrange to the 5-1/4" woofers, which are made of a high-damping treated paper for nuanced sound and precise play. The 1" tweeters handle the high-frequency acrobatics with ease, thanks to dynamic neodymium magnets. And the tweeter's silk dome structure delivers that smooth sound you listen for in your highs.

• component system includes two woofers, two 1" tweeters, and two crossovers
• 5-1/4" coated paper woofer with rubber surround
• 1" silk dome tweeter
• tweeter flush-mounting and top-mounting gear included
• works with factory radio, aftermarket receiver, or outboard amp
• 2-40 watts RMS power range (120 watts peak)
• frequency response: 65-22,000 Hz
• impedance: 4 ohms
• sensitivity: 90 dB
• woofer mounting depth: 1-7/8"

If you know Audiotec Fischer's commitment to quality, then you probably have an idea of how exquisite their MATCH Series of speakers sound. The MS42C component system uses finely tuned, compact external crossover networks for a seamless frequency response. The crossovers assign the lows and midrange to the 4" woofers, which are made of a high-damping treated paper for nuanced sound and precise play. The 1" tweeters handle the high-frequency acrobatics with ease, thanks to dynamic neodymium magnets. And the tweeter's silk dome structure delivers that smooth sound you listen for in your highs.

• the component system includes two woofers, two 1" tweeters, and two crossovers
• 4" coated paper woofer with rubber surround
• 1" silk dome tweeter
• tweeter flush-mounting and top-mounting gear included
• works with factory radio, aftermarket receiver, or outboard amp
• 2-35 watts RMS power range (105 watts peak)
• frequency response: 90-20,000 Hz
• impedance: 4 ohms
• sensitivity: 89 dB
• woofer mounting depth: 1-3/4"

• 12" subwoofer with 4-ohm voice coil
• silk-coated Agave sisalana woofer cone with rubber surround
• die-cast aluminum basket
• frequency response: not available
• power handling: 100-350 watts RMS
• peak power: 700 watts
• sensitivity: 87.3 dB
• top-mount depth: 5-9/16"
• sealed box volume: 0.75 cu. ft.
• ported box volume: 1.50 cu. ft.

Helix builds their Esprit subwoofers to fit in places that normal subs won't. Coming in at just 3-1/8" deep, the Esprit E10W 10" shallow-mount sub lets you get creative with placement while giving you impressive bass. German engineering shines through on this sub, as Helix uses technology from their high-end Precision Series to create a super-slim driver that delivers superior performance and handles plenty of power. You'll enjoy highly accurate bass reproduction in applications where space is an issue.

• 10" shallow-mount subwoofer with dual 2-ohm voice coils
• fiberglass coated honeycomb membrane woofer with rubber surround
• die-cast aluminum frame
• power range: 100-300 watts RMS (450 watts peak power)
• frequency response: not available
• sensitivity: 88 dB
• top-mount depth: 3-1/8"
• sealed box volume: 0.75 cubic feet
• ported box volume: 1.50 cubic feet

Based on our basic principles “handmade” and “made in Germany” we have designed the amplifier BRAX MX4 according to the latest technical knowledge. The result is both a top-class amplifier and a true high-end statement: A long-lasting period of research and development, innovative technologies and an extremely fastidious manufacturing combined with the love for music as the driving force for our work make the BRAX MX4 doubtlessly to the most powerful and best sounding 4-channel amplifier of the world.

Concerning the straight design of the MX4-amplifier and the sophisticated layout of the circuit board, we have deliberately set crossovers and filter functions aside. Short signal paths combined with selected components “made in Germany” ensure pristine listening pleasure and underline the puristical high-end philosophy of the BRAX MX4.

In order to completely eliminate power differences and manufacturing tolerances, we only use hand-selected transistors for the production of each MX4-amplifier. Concerning power-, voltage- and resistance data we select them in more than 300 categories. Thus, all transistors harmonize perfectly in terms of technical specifications. In doing so, our BRAX amplifiers obtain a worldwide reference status. Striving for ultimate perfection, Audiotec Fischer is the only manufacturer of audiophile products on the globe that conducts this extensive and time-consuming hand-selection. Of course, all the instruments that are necessary for this procedure are in-house developments.

Two separate power supplies for the channels A/B and C/D account for an endlessly stable power output. The amplifier’s output is even stable when you connect loudspeakers and a woofer with different impedances to the BRAX MX4. In order to control voltage fluctuations, an external power stabilizer can directly be connected to the power supply. Moreover, the solid and gold-plated terminals for cables up to 50mm² make another contribution to an ideal power supply of the BRAX MX4.

At the end of the day, the BRAX MX4 can be described as an amplifier with a sound rendition that is highly dynamic, powerful in an awesome way and swift as an arrow. The underlying philosophy is topped-off by a packaging in a precious wooden box. Furthermore, every single amplifier is manufactured individually and its respective serial number is recorded in our database. The amplifier BRAX MX4 is only produced on demand and of course, we can respond to our customer’s requirements. In this way, each amplifier is a valuable individual item that rightly deserves the title “high-end made in Germany”.

• Optical digital inputs used for the upcoming BRAX DSP (2 x Toslink)
• Separate terminal for connecting a BRAX Power Stabilizer directly to the switching transistors
• Eight capacitors (with a total capacity of 40,000 microFarad) take care of an extremely high current impulse load
• 200 Ampere high-performance switching transistors
• Interference-free power supply due to optimized suppression coil up to 300 Ampere with ultra-low internal resistance
• Especially developed transformers with highly-efficient core materials guarantee a total performance of more than 1,800 Watts
• High efficiency due to super-fast Schottky power diodes with more than 160 Ampere in total
• Below the lateral PC-boards, there are in total 32 hand-selected high-end MOSFET transistors which account for brilliant sound
• Processor controlled operating data management of the amplifier and power supply. It also controls the optional fan. Furthermore, the processor is supervising the whole amplifier and shuts it down in case of malfunctions
• Engraved serial number on the stainless steel plate
• Impedance independent output power of around 280 Watts per channel
• 4-, 2- and 1-Ohms stable
• Optional fan at the bottom plate with processor supported fan control
• The solid heatsink, made of a special aluminum alloy takes care of a perfect cooling of power supply transistors and those of the amplifier
